OPS
Onshore Power Supply (OPS) allows a ship docked at berth to shut down its onboard generators and draw electric power directly from shore, drastically cutting emissions, noise and fuel usage.
Under EU policy (e.g. AFIR), ports must deploy OPS infrastructure by 2030 to meet demand from passenger, container and other vessels.
In practice, OPS systems require robust high-voltage or medium-voltage connections, protective switchgear, and safe interfaces adapted to ship and grid requirements.
By enabling ships to “plug in” rather than run engines in port, OPS plays a key role in decarbonizing maritime operations and improving urban air quality.
Large vessels
CLICK ON THE VESSEL TYPE YOU WANT TO CONNECT
3PX4-LV
IEC 60309-1
250A max.
690V max.
-
Poles
3P+E+4p -
Section max.
70 mm² AWG 2/0 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX5-LV
IEC 80005-3
IEC 60309-5
350A max.
690V max.
-
Pole
3P+E+4p -
Section max.
185 mm² AWG 350 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX5-MV
IEC 80005-1
Annnex D
IEC 62613-2
Annnex I
350A max.
7,2kV max.
-
Poles
3P+E+3p -
Section max.
185 mm² AWG 350 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX7
IEC 80005-1
Annnex B
IEC 62613-2
Annnex J
500A max.
12kV max.
-
Poles
3P+E+7p -
Section max.
240 mm² AWG 500 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX7
IEC 80005-1
Annnex E
IEC 62613-2
Annnex J
500A max.
12kV max.
-
Poles
3P+E+7p -
Section max.
240 mm² AWG 500 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX7
IEC 80005-1
Annnex F
IEC 62613-2
Annnex J
500A max.
12kV max.
-
Poles
3P+E+7p -
Section max.
240 mm² AWG 500 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX7
IEC 80005-1
Annnex G
IEC 62613-2
Annnex J
500A max.
12kV max.
-
Poles
3P+E+7p -
Section max.
240 mm² AWG 500 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX7
IEC 80005-1
Annnex H
IEC 62613-2
Annnex J
500A max.
12kV max.
-
Poles
3P+E+7p -
Section max.
240 mm² AWG 500 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX6-MV
IEC 80005-1
Annnex C
CMS supply only
500A max.
12kV max.
-
Poles
3P+E+7p -
Section max.
240 mm² AWG 500 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PXU-MV
IEC 80005-1
Annnex C
CMS supply only
250A max.
12kV max.
-
Pole
1P (neutral) -
Section max.
240 mm² AWG 500 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX3 24p
IEC 80005-1
Annnex C
30A max.
500V max.
-
Poles
23P+E -
Section max.
6 mm² AWG 10 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
3PX7
IEC 80005-1
Annnex I
IEC 62613-2
Annnex J
500A max.
12kV max.
-
Poles
3P+E+7p -
Section max.
240 mm² AWG 500 -
Ind. protection
IP67 - IK10 -
Temperature
-30 +60°C
